For those looking to drill a dog hole grid/MFT-style table top, this is a means to do so affordably and efficiently.
This jig is spaced at 96mm on center, which is standard in MFT tops for 20mm dog holes. It is intended to be used with a 7/8" ID/1" OD guide bushing on a plunge router of your choice and with the recommended 20mm dog hole router bit (Trend C030DX1/2TC).
*While other 20mm router bits will work, I found the Trend brand bit to be most effective for the repetitive plunge cuts that are made while drilling dog holes. Additionally, it comes in a standard 1/2" collet size, while many other 20mm boring bits require a metric collet. Overall, it also held up very well. The picture you see in the listing is after cutting 180 dog holes in a 1 1/2" MDF table top. Additionally, the item is listed as 25/32" cutting diameter, but it is actually 20mm.
Why choose 20mm over 3/4"? Because there are more precision accessories available for 20mm dog holes. UJK is a fantastic brand for these accessories if you're interested, but even if you don't plan on splurging on some rails, dogs, etc. from them, it's nice to know they'll fit if you ever decide to.
*NOTE: this jig is affordable, and reasonably accurate. If you are looking for absolute precision, this jig is not for you. When checking for square on my benchtop, most of the holes were somewhere between 1/32"-1/16" out of square over a 24" run.
Purchase includes:
-Dog Hole Routing Template
-4x Guide Pins
Dimensions:
Plate: 10.7" (272mm) x 10.7" (272mm)
Thickness: 1/4"
Spacing: 96mm on center between holes
Guide pins: fits 20mm dog holes
Guide holes: fits 1"OD guide bushing
Links:
How to Use
Trend C030DX1/2TC 20mm dog hole router bit ($44.00)
Guide bushing set I used ($29.99)
This is a patented and legally protected design property of DeAngelis Woodcraft. Any attempt to copy or sell will result in legal action against you or your business.
Buy any 3 models of this jig to get $5 off the order total. This discount applies continuously if you order another set of 3, etc.
Hidden barrel hinges can be a pain to install and require a fair amount of precision to get right. With this jig, you can use a center punch or awl to align everything perfectly and ensure a proper fit.
This design is intended for use with the following brand/model hidden barrel hinges:
Rockler
10mm - #28555
12mm - #13516
14mm - #28563
SOSS
8mm - BHC085
10mm - BHC104
12mm - BHC124
14mm - BHC144
16mm - BHC164
18mm - BHC184
24mm - BHC244
*If you are using a different brand, these may not work. Manufacturer’s specifications are included in listing photos so you can check.
*NOTE: I have not had the chance to use every type of jig listed first-hand. Therefore, I'd advise trying any given jig on a test board BEFORE using it on your project. If you notice any issues, please reach out!
Purchase includes:
2x Jig of your choice
Links:
Rockler Hidden Barrel Hinges
SOSS Barrel Hinges
This is a patented and legally protected design property of DeAngelis Woodcraft. Any attempt to copy or sell will result in legal action against you or your business.
Upgrade your Ridgid Oscillating Edge Belt/Spindle Sander's dust collection 10-fold!
I made this port for my own shop to cut down on the large quantities of fine dust this machine throws into the air. Before, I was hesitant to use this tool because it's dust collection was so bad, but now it clears dust like a champ. This improved dust port won't just keep your lungs healthy, but also keep your shop and tool bed clean while you work, resulting in a more pleasurable and accurate sanding experience.
Dimensions:
Dust Port OD: 2.44" or 62mm
Dust Port ID: 2.13" or 52mm
Height: 5.12" or 130mm
*NOTE: The port has a tendency to lean back if the hose attached to is not properly supported. To fix this, find a way to support the weight of the hose, or use some double-sided tape to better secure the port to the sander bed. While not ideal, during design, I preferred the simplicity of mounting via the thumb screw over needing to modify the metal bed.*
*NOTE: I have not been able to test the fit on the older models of this sander, but from my research it should fit on these as well.
This is a patented and legally protected design property of DeAngelis Woodcraft. Any attempt to copy or sell will result in legal action against you or your business.
